| YANMAR M220 |
| SR NO | ITEM | PART NO | QTY |
| 2 | BALL BEARING 6207U | 24102-062074 | 3 |
| 3 | BOLT M12X40 | 26116-120402 | 10 |
| 4 | BUSH | 138613-72160 | 1 |
| 5 | COLLAR PUMP T=2 | 141616-42261 | 3 |
| 6 | COTTER PIN 3.2X32 | 22417-320320 | 8 |
| 7 | GASKET | 137602-18151 | 3 |
| 8 | GASKET | 44100-018310 | 2 |
| 9 | GASKET | 139684-39060 | 4 |
| 10 | GASKET 1.0T | XNN164605 | 12 |
| 11 | GASKET 10X1.0 | 23414-100000 | 44 |
| 12 | GASKET 10X1.0 | 23418-100000 | 10 |
| 13 | GASKET 12X1.0 | 23414-120000 | 80 |
| 14 | GASKET 14X1.0 | 23414-140000 | 40 |
| 15 | GASKET SAFETY VALVE | 141616-15100 | 18 |
| 16 | GASKET ZINC | 137800-33380 | 6 |
| 17 | HANDEL | 15323-15340 | 2 |
| 18 | LOCK RING | XNN169911 | 6 |
| 19 | NUT | 26733-160002 | 2 |
| 20 | O RING | 136600-42040 | 3 |
| 21 | O RING | 134674-51381 | 28 |
| 22 | O RING 1AP11.0 | 24311-000110 | 140 |
| 23 | O RING 1AP14.0 | 24311-000140 | 8 |
| 24 | O RING 1AP20.0 | 24311-000200 | 110 |
| 25 | O RING 4CG35.0 | 24324-000350 | 2 |
| 26 | O RING 4DG65.0 | 24326-000650 | 10 |
| 27 | O RING 4DP12.5 | 24316-000125 | 10 |
| 28 | O RING 4DP22A | 24316-350220 | 4 |
| 29 | OIL THROWER 78 | XNN169942 | 6 |
| 30 | PACKING | 137600-52490 | 6 |
| 31 | PACKING | XP2618210NA | 12 |
| 32 | PACKING | XP3426215NA | 6 |
| 33 | PACKING AIR VENT | 138613-35300 | 12 |
| 34 | PACKING AIR VENT | 138613-35280 | 6 |
| 35 | PACKING CASE | 137600-55910 | 6 |
| 36 | PACKING CASE | 138613-35261 | 6 |
| 37 | PACKING ELEMENT | 137600-55930 | 6 |
| 38 | PACKING GUIDE | 138613-35330 | 6 |
| 39 | PACKING START VALVE | 146613-71090 | 23 |
| 40 | PACKING STRAINER | 142613-35100 | 12 |
| 41 | PACKING ZINC | 132310-09330 | 12 |
| 42 | PARALLEL PIN | 22312-060120 | 18 |
| 43 | PARALLEL PIN M12X30 | 22312-120300 | 2 |
| 44 | PIN | 141616-11601 | 17 |
| 45 | PISTON RING | XNN169912 | 6 |
| 46 | RETAINER | 138623-11350 | 2 |
| 47 | SEAL | 147644-11581 | 1 |
| 48 | SEAL OIL | 24411-254008 | 6 |
| 49 | SEAL OIL | 24421-355511 | 3 |
| 50 | SEAL OIL TCN | 141646-52660 | 42 |
| 51 | SHAFT | 141646-52132 | 3 |
| 52 | SPRING VALVE | 146613-71130 | 1 |
| 53 | STUD M12X70 | 26216-120702 | 2 |
| 54 | WASHER | 141616-42270 | 3 |
| 55 | WASHER LOCK | 140623-83910 | 3 |
| 56 | NOZZLE | 147644-53010 | 2 |
| 57 | VALVE IN | 150673-11101 | 1 |
| 58 | VALVE EX | 150673-11113 | 2 |
| 59 | SEAT IN | 147644-11081 | 1 |
| 63 | SPRING (B) VALVE | 137678-11131 | 2 |
| 64 | AIR SELF GEAR | | 1 |
| 65 | METAL ASSY, CRANK PIN | 147644-23400 | 10 |
| 66 | METAL ASSY MAIN | 147644-02250 | 7 |
| 67 | RING SET PISTON | 747644-22503 | 7 |
| 68 | THRUST METAL ASSY | 150623-02501 | 4 |
| 69 | BUSH | 147644-02500 | 5 |
| 70 | BUSH PISTON PIN | 147644-23100 | 5 |
| 71 | TAPPET ASSY | 741616-14400 | 7 |
| 74 | GUIDE VALVE | 147644-11150 | 13 |
| 76 | SHAFT ROCKER ARM | 147644-11250 | 1 |
| 78 | RING PISTON NO2 | 150623-22180 | 2 |
| 79 | RING NO 1 | 150623-22160 | 6 |
| 80 | RING NO 1 | 150623-22170 | 6 |
| 81 | STARTING VALVE | YANMAR | 1 |
| 82 | ROTATOR | 27320-160620 | 4 |
| 83 | SPACER VALVE STOP | 139684-53240 | 11 |
